For more than 40 years, Mobil SHC™ 600 Series synthetic circulating and gear oils have delivered premium performance and maximized production uptime in industrial gearboxes operating in extreme temperatures and under heavy loads.
Recommended for use in more than 1,800 applications by more than 500 major equipment builders, Mobil SHC 600 Series synthetic lubricants continue to be recognized by OEMs addressing specific lubrication challenges while maintaining excellent overall performance.
Mobil SHC 600 Series synthetic lubricants can reduce energy consumption in gearboxes and circulating systems by up to 3.6 percent*. They can also:
- Extend oil life by up to six times vs. conventional oil
- Offer similar seal and metals compatibility as conventional oils
- Operate in a wide range of industrial applications
{0} offers {1} lubricant grades
<%= raw.productdescription%>
<%= raw.marketindustrialproducttypeandfeature %> <% } else { %> <%= title ? title : '' %>
<%= raw.productdescription%>
<%= raw.marketindustrialproducttypeandfeature %> <% } %>
Features and Benefits
The Mobil SHC brand of lubricants are recognized and appreciated around the world for their innovation and outstanding performance. These synthetic products, molecularly designed and pioneered by our research scientists, embody the continuing commitment to using advanced technology to provide outstanding lubricant products. The development of Mobil SHC 600 Series was preceded by close contacts between our scientists and application specialists with key Original Equipment Manufacturers (OEMs) to ensure that the products provide exceptional performance in the continually evolving industrial equipment designs.
Our work with key equipment builders has helped confirm the results from our own laboratory and rig tests showing the exceptional performance of Mobil SHC 600 Series lubricants. Not least among the benefits, shown in work with OEMs, is the potential for energy efficiency improvements up to 3.6% relative to mineral oils (*). These benefits are particularly evident in equipment with a high level of mechanical losses, such as high ratio worm gears.
To develop the latest Mobil SHC technology for Mobil SHC 600 Series oils, our product formulation scientists chose select base oils because of their exceptional thermal/oxidative resistance potential and combined them with a balanced additive system, which complements the inherent benefits of the base oils to provide excellent oil life, deposit control and resistance to thermal/oxidative and chemical degradation. This formulation approach provides low temperature fluidity characteristics exceeding that of many conventional mineral products and is a key benefit for remote, low ambient temperature applications. Mobil SHC 600 Series oils offer the following features and potential benefits:
(*) Energy efficiency relates solely to the performance of Mobil SHC 600 when compared to conventional (mineral) reference oils of the same viscosity grade in circulating and gear applications. The technology used allows up to 3.6% efficiency compared to the reference when tested in a worm gearbox under controlled conditions. Efficiency improvements will vary based on operating conditions and application.
Features |
Advantages and Potential Benefits |
Superb high temperature thermal/oxidation resistance |
Helps extend equipment high temperature operating capability Long oil life, helps reduce maintenance costs Helps minimize deposits to enable trouble-free operation and long filter life |
High Viscosity Index and absence of wax |
Maintains viscosity and film thickness at high temperatures Helps enable exceptional low temperature performance, including start-up |
Low traction coefficient |
Helps reduce friction and increase efficiency in sliding mechanisms such as gearing, with potential for reduced power consumption and lower steady-state operating temperatures. Helps minimize the effects of micro slip in rolling contact bearings to potentially extend rolling-element life |
High load carrying capability |
Helps protects equipment and extends life; helps minimize unexpected downtime and extends service periods |
Balanced additive combination |
Provides excellent performance in terms of rust and corrosion prevention, water separability, foam control and air release performance enabling problem-free operation in a wide range of industrial applications, and reduced operating costs |
Applications
While Mobil SHC 600 Series are generally compatible with mineral oil based products, admixture may detract from their performance. Consequently it is recommended that before changing a system to one of Mobil SHC 600 Series products, it should be thoroughly cleaned out and flushed to achieve the maximum performance benefits. Mobil SHC 600 Series oils are compatible with most NBR, FKM and most other elastomeric seal materials that are used with mineral oils. There is the potential for substantial variations in the elastomers. For best results, consult your equipment supplier, seal manufacturer, or your local company representative to verify compatibility.
Mobil SHC 600 Series lubricants are recommended for use in a wide variety of gear and bearing applications where high or low temperatures are encountered or where operating temperatures or bulk oil temperatures are such that conventional lubricants give unsatisfactory life, or where improved efficiency is desired. They are particularly effective in applications where the maintenance costs of component replacement, system cleaning and lubricant changes are high. Specific applications require selection of the appropriate viscosity grade and include:
• Filled for life gearboxes, especially high ratio/ low-efficiency worm gears
• Remotely located gearboxes, where oil change-out is difficult
• Low temperature applications, such as ski lifts where seasonal oil changes can be avoided
• Mixer roll bearings and roll neck bearings where high temperatures are encountered
• Plastic calenders
• Severe centrifuge applications, including marine centrifuges
• Railroad A/C Traction Drives
• Mobil SHC 626, 627, 629 and 630 are suitable for Oil Flooded Rotary Screw Compressors compressing natural gas, field gas gathering, CO2 and other process gasses used in the natural gas industry
• Mobil SHC 629, 630, 632, 634, 636, and 639 are approved by Siemens AG for use in Flender gearboxes
Specifications and Approvals
This product has the following approvals: |
624 |
625 |
626 |
627 |
629 |
630 |
632 |
634 |
636 |
639 |
Flender |
|
|
|
|
X |
X |
X |
X |
X |
|
GE D50E32 AC Traction Motor |
|
|
|
|
|
|
|
X |
|
|
SEW-Eurodrive |
X |
|
X |
|
X |
X |
X |
X |
X |
X |
This product is recommended for use in applications requiring: |
624 |
625 |
626 |
627 |
629 |
630 |
632 |
634 |
636 |
639 |
Fives Cincinnati P-34 |
|
|
|
|
|
|
|
|
X |
|
Fives Cincinnati P-63 |
|
|
X |
|
|
|
|
|
|
|
Fives Cincinnati P-76 |
|
|
|
X |
|
|
|
|
|
|
Fives Cincinnati P-77 |
|
|
|
|
X |
|
|
|
|
|
Fives Cincinnati P-78 |
|
|
|
|
|
|
|
|
|
X |
Fives Cincinnati P-80 |
|
|
X |
|
|
|
|
|
|
|
This product meets or exceeds the requirements of: |
624 |
625 |
626 |
627 |
629 |
630 |
632 |
634 |
636 |
639 |
AGMA 9005-F16 |
X |
X |
X |
X |
X |
X |
X |
X |
X |
X |
DIN 51517-3:2018-09 |
|
|
|
X |
X |
X |
X |
X |
X |
X |
ISO L-CKB (ISO 12925-1:2024) |
X |
|
|
|
|
|
|
|
|
|
ISO L-CKD (ISO 12925-1:2018) |
|
|
|
|
|
X |
X |
X |
X |
X |
ISO L-CKD (ISO 12925-1:2024) |
|
X |
X |
X |
X |
|
|
|
|
|
Properties and Specifications
Property |
624 |
625 |
626 |
627 |
629 |
630 |
632 |
634 |
636 |
639 |
Grade |
ISO VG 32 |
ISO VG 46 |
ISO VG 68 |
ISO VG 100 |
ISO VG 150 |
ISO VG 220 |
ISO VG 320 |
ISO VG 460 |
ISO VG 680 |
ISO VG 1000 |
Appearance, AMS 1738 |
Orange |
Orange |
Orange |
Orange |
Orange |
Orange |
Orange |
Orange |
Orange |
Orange |
Copper Strip Corrosion, 24 h, 121 C, Rating, ASTM D130 |
1B |
1B |
1B |
1B |
1B |
1B |
1B |
1B |
1B |
1B |
Density @ 60 F, kg/m3, ASTM D4052 |
0.85 |
0.85 |
0.86 |
0.86 |
0.86 |
0.87 |
0.87 |
0.87 |
0.87 |
0.87 |
Emulsion, Time to 37 mL Water, 54 C, min, ASTM D1401 |
10 |
15 |
15 |
|
|
|
|
|
|
|
Emulsion, Time to 37 mL Water, 82 C, min, ASTM D1401 |
|
|
|
15 |
20 |
20 |
20 |
20 |
20 |
25 |
FE8 wear test, V50 roller wear, mg, DIN 51819-3 |
|
|
|
2 |
2 |
2 |
2 |
2 |
2 |
2 |
FZG Scuffing, Fail Load Stage, A/8.3/90, ISO 14635-1(mod) |
11 |
12 |
12 |
12 |
13 |
13+ |
13+ |
13+ |
13+ |
13+ |
Flash Point, Cleveland Open Cup, °C, ASTM D92 |
236 |
225 |
225 |
235 |
220 |
220 |
225 |
228 |
225 |
222 |
Kinematic Viscosity @ 100 C, mm2/s, ASTM D445 |
6.3 |
8.5 |
11.6 |
15.3 |
21.1 |
28.5 |
38.5 |
50.7 |
69 |
98.8 |
Kinematic Viscosity @ 40 C, mm2/s, ASTM D445 |
32 |
46 |
68 |
100 |
150 |
220 |
320 |
460 |
680 |
1000 |
Pour Point, °C, ASTM D5950 |
-57 |
-54 |
-54 |
-48 |
-48 |
-48 |
-48 |
-45 |
-45 |
-42 |
Rotating Pressure Vessel Oxidation Test, min, ASTM D2272 |
2500 |
2500 |
2500 |
2500 |
2500 |
2500 |
2500 |
2500 |
2500 |
2500 |
Rust Characteristics, Procedure B, ASTM D665 |
PASS |
PASS |
PASS |
PASS |
PASS |
PASS |
PASS |
PASS |
PASS |
PASS |
Turbine Oil Stability Test, Life to 2.0 mg KOH/g, h, ASTM D943 |
10,000+ |
10,000+ |
10,000+ |
10,000+ |
10,000+ |
10,000+ |
10,000+ |
10,000+ |
10,000+ |
10,000+ |
Viscosity Index, ASTM D2270 |
148 |
161 |
165 |
162 |
166 |
169 |
172 |
174 |
181 |
184 |
Health and Safety
Health and Safety recommendations for this product can be found on the Material Safety Data Sheet (MSDS) @ http://www.msds.exxonmobil.com/psims/psims.aspx
