Mobil SHC™ 630 paper manufacturing gear oil success story

Reduced grease consumption by

76%
grease consumption reduce
Paper machine gearbox oil

Situation

Asia Kraft Paper Co., Ltd. is a packaging paper manufacturer with two Allimand paper machines. Using a non-Mobil™ gear oil for machine lubrication, the gearbox was experiencing excessive wear as the operating temperature was running up to 70°C. This caused oxidation and the need for an oil change every three months.

Recommendation

The Mobil Lube Engineer analyzed the situation and recommended Mobil SHC™ 630 gear and bearing oil. This recommendation was supported by Mobil ServSM Lubricant Analysis monitoring.

Result

After two and a half years of continuous operation and monitoring, Mobil SHC 630 gear and bearing oil has proven to be an excellent choice. The operating temperature of the gearbox decreased from 70°C to 50°C with no further wear observed on gear teeth. The oil drain interval has also increased from three months to 24 months, thereby improving productivity by reducing unscheduled downtime by up to 18 days. As a result of deploying Mobil SHC 630, the savings on spare parts and labour cost amounted to approximately US $9,500 annually.

*This success story is based on the experience of a single customer. Actual results can vary depending upon the type of equipment used and its maintenance, operating conditions and environment, and any prior lubricant used.
